FCRMX41B – Includes Air Cut Off Valve and Hot Start Data Set
| 5 | Top | 1030-897-2000 |
| 6 | Gasket | 1202-895-6000 |
| 7 | Screw (M4 x12) | 0136-806-1100 |
| 8 | Screw (M4 x 8) | 0136-808-1100 |
| 10 | Bracket | 1190-840-2101 |
| 11 | Screw | 93500-05008-1H |
| 12 | Throttle Shaft Comp. | 5025-B35-2201 |
| 14 | Coil Spring | 1305-A83-2000 |
| 15 | Washer | 0301-092-7000 |
| 16 | Link Arm Comp. | 1061-831-2101 |
| 18 | Stop Screw | 4110-825-1100 |
| 19 | Throttle Valve | N501-49C01 |
| 20 | Roller | 1119-803-7002 |
| 21 | Plate | 1609-809-2100 |
| 22 | Seal | 1099-817-6000 |
| 23 | Jet Needle | N427-0C-size |
| 24 | Clip | 0403-802-1000 |
| 25 | Set Screw | 1421-802-2000 |
| 26 | Main Nozzle | 1154-842-2000 |
| 27 | Main Jet | 99101-357-size |
| 28 | Slow Jet | N424-21-size |
| 29 | Starter Jet | 99101-393-size |
| 30 | Slow Air Jet | 99101-124-size |
| 32 | Pilot Screw | N446-07A00 |
| 33 | Coil Spring | 1290-812-2000 |
| 34 | O-Ring | 16075-KG8-9010-M1 |
| 35 | Washer | 0301-803-2000 |
| 36 | Valve Seat 3.2-4mm | N361-04-size |
| 37 | O-Ring | 16958-397-7710-M1 |
| 38 | Screw | 0118-806-1100 |
| 39 | Float Comp. | 1052-856-2100 |
| 40 | Arm Pin | W9525-25250 |
| 42 | Float Value 3.2-4mm | 1062-814-2101 |
| 43 | Clip | 0405-019-1000 |
| 44 | Fuel Screen | 2009-811-2100 |
| 45 | O-Ring | 1202-896-6000 |
| 46 | Drain Screw | 1198-810-2002 |
| 47 | Cover | 1230-826-2002 |
| 49 | Float Bowl Comp. | 1050-948-2101 |
| 51 | Diaphragm Comp. | 1201-858-2700 |
| 52 | U-Ring | W9353-36000 |
| 53 | Coil Spring | 1300-142-2000 |
| 54 | O-Ring | 16178-548-0040 |
| 55 | Starter Valve Comp. | 1166-844-2100 |
| 64 | Link Lever | 1100-914-2100 |
| 65 | Link Lever # 2 | 1100-915-7000 |
| 66 | Coil Spring # 1 | 1305-B01-2001 |
| 67 | Coil Spring # 2 | 1305-A82-2000 |
| 69 | Washer | W1795-223-9900 |
| 70 | E-Clip | 16179-676-3000 |
| 72 | Rod | 1458-858-2001 |
| 83 | Fuel Joint | 1074-895-2100 |
| 85 | O-Ring | W9351-13057 |
| 90 | Idle Speed Screw | 1034-815-4500 |
| 91 | Washer | 0301-078-1200 |
| 92 | Coil Spring | 1300-112-2000 |
| 100 | Screw (M4 x 8) | 0136-804-1100 |
| 103 | Main Air Jet | 99101-393-size |
| 122 | O-Ring | 16173-001-0040 |
| 123 | Drain Bolt | 16162-ND4-7511-M1 |
| 140 | Screw | 0110-804-1200 |
| 148 | Vent Hose | 0803-884-0100 |
| 152 | Hose Clip | W9535-35000 |
| 177 | Stop Screw | 1034-905-2000 |
| 205 | Hose Retainer | 16179-KZ4-6900 |
| 206 | Vent Hose | 0803-878-0000 |
| 207 | Vent Hose | 95003-07033-31 |
| 209 | Buffer Plate | 1157-812-7000 |
| 211 | Diaphragm Comp. | W1470-MW0-7500 |
| 212 | Cover | 1230-850-2000 |
| 213 | Coil Spring | 1290-A19-2000 |
| 243 | Coil Spring | 1290-A65-2000 |
| 244 | Collar | 1118-B36-2000 |
| 245 | Hot Start Valve | 1166-845-2100 |
| 249 | Washer | W1795-164-9900 |
| 250 | Stop Screw | 16124-KR3-6010-M1 |
| 251 | Coil Spring | 16053-KT7-0030 |
| 264 | Cover | 1230-869-7001 |
| 265 | Cover Screw | 0136-839-1100 |
| MOUNT TYPE | Spigot | MAIN JET | 99-101-357-Size | 160 |
| TICKOVER POSITION | Left | PILOT JET | N424-21-Size | 45 |
| COLD START POSITION | Left | NEEDLE JET | Fixed | — |
| COLD START TYPE | Knob | JET NEEDLE | N427-OC-EMR | Clip groove #4 |
| AIR SCREW POSITION | — | STARTER JET | — | — |
| FLANGE PITCH (MM) | — | PILOT AIR JET | 99-101-124-Size | 100 |
| FRONT SPIGOT DIAMETER (MM) | 48 | MAIN AIR JET | 99-101-393-Size | 200 |
| REAR SPIGOT DIAMETER (MM) | — | |||
| LENGTH (MM) | 63.5 | THROTTLE VALVE | N501-49C01 | 1.5 |
| HEIGHT OVER BORE CENTRELINE (MM) | — | FLOAT VALVE | 1062-814-2100 | — |
| HEIGHT UNDER BORE CENTRELINE (MM) | — | — | — | — |
| FUEL INLET POSITION | Left | — | — | — |
| FLOAT HEIGHT (MM) | 9 | — | — | — |
| FUEL SPIGOT (MM) | 8 |
