VM22-133 Data Set
| MOUNT TYPE | Flange | MAIN JET | 4/042-Size | 100 |
| TICKOVER POSITION | Left | PILOT JET | VM22/210-Size | 30 |
| COLD START POSITION | Left | NEEDLE JET | (257) | N-8 |
| COLD START TYPE | Lever | JET NEEDLE | J8-4D20 | Clip groove #3 |
| AIR SCREW POSITION | Left | STARTER JET | Fixed | — |
| FLANGE PITCH (MM) | 50 | PILOT AIR JET | 48 | — |
| CLAMP DIA (MM) | — | PILOT AIR SCREW | — | — |
| FRONT SPIGOT DIAMETER (MM) | — | MAIN AIR JET | Fixed | — |
| REAR SPIGOT DIAMETER (MM) | 43 | POWER JET | — | — |
| LENGTH (MM) | 84.5 | THROTTLE VALVE | VM26/21-Size | 2.0 |
| HEIGHT OVER BORE CENTRELINE (MM) | 82 | FLOAT VALVE | VM26/26-Size | 2.0 |
| HEIGHT UNDER BORE CENTRELINE (MM) | 57 | — | — | — |
| FUEL INLET POSITION | Right | — | — | — |
| FLOAT HEIGHT (MM) | 25 | — | — | — |
| FUEL SPIGOT (MM) |
| 1 | Dust Cover: Cable Adjuster | VM26/46 |
| 2 | Cable Adjuster | M21/14 |
| 3 | Locknut: Cable Adjuster | B30/247 |
| 4 | Carburettor Top | VM26/44 |
| 5 | Seal: Carburettor Top | VM26/57 |
| 6 | Spring: Throttle Return | VM24/195 |
| 7 | Retaining Plate: Jet Needle | VM26/55 |
| 8 | E Clip: Jet Needle | VM18/341 |
| 9 | Jet Needle | # |
| 10 | Throttle Valve | VM26/21-size |
| 11 | Needle Jet | 257-N-8 |
| 12 | Dust Cover: Cold Start Assy | ? |
| 13 | Retainer: Cold Start Assy | ? |
| 14 | Lever: Cold Start Assy | ? |
| 15 | Indexing Plate | ? |
| 16 | Spring: Cold Start Assy | ? |
| 17 | Plunger: Cold Start Assy | ? |
| 18 | Carburettor Body | N/A |
| 19 | Gasket: Float Bowl | VM28/18 |
| 20 | Float Bowl Baffle Plate | N.A |
| 21 | Pilot Jet | VM22/210-size |
| 22 | Pivot: Float Arm | ? |
| 24 | Float | ? |
| 25 | Float Bowl | ? |
| 26 | Gasket: Float Bowl Drain Screw | ? |
| 27 | Float Bowl Drain Screw | ? |
| 29 | Pilot Air Screw | ? |
| 30 | Spring: Pilot Air Screw | ? |
| 31 | Spring: Tickover Screw | ? |
| 32 | Tickover Screw | ? |
| 33 | Gasket: Float Valve Assy | ? |
| 34 | Float Valve Assy | VM26/26-size |
| 35 | Baffle: Main Jet | ? |
| 36 | Main Jet | 4/042-size |
| 37 | Retainer: Vent Hose | ? |
| 42 | O-Ring: Carb Flange | 244/765 |
| 43 | Drain Screw/Main Jet Holder | VM24/286 |
| 44 | Gasket: Drain Screw | 30BIC/35 |
| 45 | O-ring: Main jet | BV32/04 |
